Welcome to the official website of Lihong Safety Equipment Engineering (Shanghai) Co., Ltd.!

Position首頁(yè) > Home > Industrial Safety Products > Sensor > Safety Light Curtain

LC4 cascade safety grating

·Security level reaches Type 4, PLe.

·The protection height is 140mm to 1420mm.

·A protection system consisting of a set of main gratings and 1 ~ 3 sets of auxiliary gratings, transmission lines and accessories.

·Four sets of gratings can be connected in series, and the total number of beams can reach 288 at most.

·Can realize the "serial setting" with increased detection height

·Set ",L-shaped setting and U-shaped setting of multi-sided protection.

·Pass TUV safety certification

▊

Directives and standards

EU directive

Machinery Safety Directive 2006/42/EC and EMC Directive 2014/30/EUU

European Standards

EN 61496-1、EN 61496-2、EN 13849-1、EN 61326-1

international standard

IEC 61496-1、IEC 61496-2、ISO 13849-1、IEC 61326-1、ISO 13855

national standard

GB/T 19436.1、GB/T 19436.2、GB 4584

▊	specifications and models

Main optical grating
serial number	model	Optical axis spacing	Detection accuracy	Detection distance	Grating type
7	LC4-10-0480mm-Z	10	15	0-6m	Main grating
8	LC4-10-0520mm-Z	10	15	0-6m	Main grating
9	LC4-10-0560mm-Z	10	15	0-6m	Main grating
10	LC4-10-0600mm-Z	10	15	0-6m	Main grating
11	LC4-10-0640mm-Z	10	15	0-6m	Main grating
12	LC4-10-0680mm-Z	10	15	0-6m	Main grating
13	LC4-10-0720mm-Z	10	15	0-6m	Main grating
14	LC4-10-0760mm-Z	10	15	0-6m	Main grating
15	LC4-10-0800mm-Z	10	15	0-6m	Main grating
16	LC4-20-0240mm-Z	20	26	0-6m	Main grating
17	LC4-20-0280mm-Z	20	26	0-6m	Main grating
18	LC4-20-0320mm-Z	20	26	0-6m	Main grating
19	LC4-20-0360mm-Z	20	26	0-6m	Main grating
20	LC4-20-0400mm-Z	20	26	0-6m	Main grating
21	LC4-20-0440mm-Z	20	26	0-6m	Main grating
22	LC4-20-0480mm-Z	20	26	0-6m	Main grating
23	LC4-20-0520mm-Z	20	26	0-6m	Main grating
24	LC4-20-0560mm-Z	20	26	0-6m	Main grating
25	LC4-20-0600mm-Z	20	26	0-6m	Main grating
26	LC4-20-0640mm-Z	20	26	0-6m	Main grating
27	LC4-20-0680mm-Z	20	26	0-6m	Main grating
28	LC4-20-0720mm-Z	20	26	0-6m	Main grating
29	LC4-20-0760mm-Z	20	26	0-6m	Main grating
30	LC4-20-0800mm-Z	20	26	0-6m	Main grating
31	LC4-20-0840mm-Z	20	26	0-6m	Main grating
32	LC4-20-0880mm-Z	20	26	0-6m	Main grating
33	LC4-20-0920mm-Z	20	26	0-6m	Main grating
34	LC4-20-0960mm-Z	20	26	0-6m	Main grating
35	LC4-20-1000mm-Z	20	26	0-6m	Main grating
36	LC4-20-1040mm-Z	20	26	0-6m	Main grating
37	LC4-20-1080mm-Z	20	26	0-6m	Main grating
38	LC4-20-1120mm-Z	20	26	0-6m	Main grating
39	LC4-20-1160mm-Z	20	26	0-6m	Main grating
40	LC4-20-1200mm-Z	20	26	0-6m	Main grating
41	LC4-20-1240mm-Z	20	26	0-6m	Main grating
42	LC4-20-1280mm-Z	20	26	0-6m	Main grating
43	LC4-20-1320mm-Z	20	26	0-6m	Main grating
44	LC4-20-1360mm-Z	20	26	0-6m	Main grating
45	LC4-20-1400mm-Z	20	26	0-6m	Main grating
46	LC4-20-1440mm-Z	20	26	0-6m	Main grating
47	LC4-20-1480mm-Z	20	26	0-6m	Main grating
48	LC4-20-1520mm-Z	20	26	0-6m	Main grating

Sub-grating
serial number	model	Optical axis spacing	Detection accuracy	Detection distance	Grating type
1	LC4-10-0260mm-F	10	15	0-6m	Sub-grating
2	LC4-10-0300mm-F	10	15	0-6m	Sub-grating
3	LC4-10-0340mm-F	10	15	0-6m	Sub-grating
4	LC4-10-0380mm-F	10	15	0-6m	Sub-grating
5	LC4-10-0420mm-F	10	15	0-6m	Sub-grating
6	LC4-10-0460mm-F	10	15	0-6m	Sub-grating
7	LC4-10-0500mm-F	10	15	0-6m	Sub-grating
8	LC4-10-0540mm-F	10	15	0-6m	Sub-grating
9	LC4-10-0580mm-F	10	15	0-6m	Sub-grating
10	LC4-10-0620mm-F	10	15	0-6m	Sub-grating
11	LC4-10-0660mm-F	10	15	0-6m	Sub-grating
12	LC4-10-0700mm-F	10	15	0-6m	Sub-grating
13	LC4-10-0740mm-F	10	15	0-6m	Sub-grating
14	LC4-10-0780mm-F	10	15	0-6m	Sub-grating
15	LC4-10-0820mm-F	10	15	0-6m	Sub-grating
16	LC4-20-0250mm-F	20	26	0-6m	Sub-grating
17	LC4-20-0290mm-F	20	26	0-6m	Sub-grating
18	LC4-20-0330mm-F	20	26	0-6m	Sub-grating
19	LC4-20-0370mm-F	20	26	0-6m	Sub-grating
20	LC4-20-0410mm-F	20	26	0-6m	Sub-grating
21	LC4-20-0450mm-F	20	26	0-6m	Sub-grating
22	LC4-20-0490mm-F	20	26	0-6m	Sub-grating
23	LC4-20-0530mm-F	20	26	0-6m	Sub-grating
24	LC4-20-0570mm-F	20	26	0-6m	Sub-grating
25	LC4-20-0610mm-F	20	26	0-6m	Sub-grating
26	LC4-20-0650mm-F	20	26	0-6m	Sub-grating
27	LC4-20-0690mm-F	20	26	0-6m	Sub-grating
28	LC4-20-0730mm-F	20	26	0-6m	Sub-grating
29	LC4-20-0770mm-F	20	26	0-6m	Sub-grating
30	LC4-20-0810mm-F	20	26	0-6m	Sub-grating
31	LC4-20-0850mm-F	20	26	0-6m	Sub-grating
32	LC4-20-0890mm-F	20	26	0-6m	Sub-grating
33	LC4-20-0930mm-F	20	26	0-6m	Sub-grating
34	LC4-20-0970mm-F	20	26	0-6m	Sub-grating
35	LC4-20-1010mm-F	20	26	0-6m	Sub-grating
36	LC4-20-1050mm-F	20	26	0-6m	Sub-grating
37	LC4-20-1090mm-F	20	26	0-6m	Sub-grating
38	LC4-20-1130mm-F	20	26	0-6m	Sub-grating
39	LC4-20-1170mm-F	20	26	0-6m	Sub-grating
40	LC4-20-1210mm-F	20	26	0-6m	Sub-grating
41	LC4-20-1250mm-F	20	26	0-6m	Sub-grating
42	LC4-20-1290mm-F	20	26	0-6m	Sub-grating
43	LC4-20-1330mm-F	20	26	0-6m	Sub-grating
44	LC4-20-1370mm-F	20	26	0-6m	Sub-grating
45	LC4-20-1410mm-F	20	26	0-6m	Sub-grating
46	LC4-20-1450mm-F	20	26	0-6m	Sub-grating
47	LC4-20-1490mm-F	20	26	0-6m	Sub-grating
48	LC4-20-1530mm-F	20	26	0-6m	Sub-grating
